NOT RECOMMENDED FOR NEW DESIGNS: SEE SC441A
SC441
POWER MANAGEMENT
Features
High Efficiency Integrated Driver for
4-Strings of 150mA LEDs
Description
?
?
?
?
?
?
?
?
?
Wide input voltage range from 4.5V to 21V
36V maximum output voltage
Drives up to 40 WLEDs in 4 strings
Programmable LED current for up to 150mA per
string
+/- 2% string-to-string current matching
Up to 90% efficiency
Wide 0.2% to 100% PWM dimming range
Possible analog dimming
Integrated 2.5A power switch
The SC441 is a high-efficiency multiple string WLED driver
with an integrated boost converter. It operates over a
wide input range from 4.5V to 21V with a maximum out-
put voltage of 36V and a 2.5A internal power switch. It
can drive up to forty WLEDs in 4 strings with current up
to 150mA per string. The string-to-string current match-
ing is 2% typical, 3% maximum. The overall efficiency is
greater than 90% due to the low current sense voltage
and a low-impedance internal power switch. The wide
PWM dimming range boasts a ratio of 500: 1.
The 800kHz switching frequency enables the user to op-
D
E S
D N
N G
E I
M S
Applications
M DE
O
Notebook Display
C W
Automotive Car Navigation Display
LED strings. This feature allows LCD panels to remain view-
E E
Sub-Notebook and Tablet Computer Displays
able even under LED failure, wire disconnect, or short-cir-
cuit conditions. The internal thermal shutdown protects
R N
the IC from overheating at abnormal conditions.
T R
O O
N F
? 800kHz switching frequency for small size
? Adjustable OVP for cost-effective output cap selection timize the external component sizes for efficiency. When
? Open/short LED protection there are fewer than 10 LEDs in each string, users can ad-
? Thermal protection with auto-recovery just the output voltage protection yielding an allowable
? Thermally enhanced TSSOP-20 EDP package reduction in associated costs, size and voltage ratings of
? Fully WEEE and RoHS compliant the output capacitor.
The SC441 also features comprehensive open and short-
circuit LED protection functions. It disables the corre-
? Medium-sized LCD panel sponding strings with LED open or LED short conditions
? while maintaining normal operation of other, unaffected
?
?
? Portable Media Players
The SC441 is available in a thermally-enhanced TSSOP-20
EDP package.
Typical Application Circuit
Vin (4.5V -21V)
1
2
VIN
SW
SW
VOUT
4 Strings
EN
FFLAG
OVPIN
PWM
COMP
SC441
OVPRTN
IO1-4
4
10
IOSET
AGND
SS
IOGND
September 28, 2010
EDP
PGND
PGND
www.semtech.com 1
